INTER-M POWER AMPLIFIER 2x450W
Product Code:L-1400
Out of stock
Controls :
Front : Power on/off switch, attenuator, LED indicators
Rear : Mode seletor switch (Stereo/Bridged Mono/Parallel HPF 50Hz/30Hz/off switch, limiter on/off switch)
Connectors :
Input : Combination jack and XLR jack (link)
Output : One 5-way binding post and one SpeakonTM per channel
Indicators : Power(Blue), Protection(Red), Clip/Limiter(Red), Signal(Green), Mode Selector(Yellow)
Filters : 30Hz HPF, 50Hz HP
Protection : Turn-on delay, thermal, DC fault, PC limiter, RF, Clip-limiter, short circuit, open circuit
Cooling : Continuously variable speed fan, front to rear air flow
Power Source : 100-120VAC or 220-240VAC; 50/60Hz
(supplied AC mains transformer depends on country requirements)
Power Consumption (1/8 power, RL=4 Ω) :
120VAC : 7A
230VAC : 3.5A
Weight : 14.4kg/31.7b
Dimensions (WxHxD) : 482x88x369mm/19x3.5x14.5in
Front : Power on/off switch, attenuator, LED indicators
Rear : Mode seletor switch (Stereo/Bridged Mono/Parallel HPF 50Hz/30Hz/off switch, limiter on/off switch)
Connectors :
Input : Combination jack and XLR jack (link)
Output : One 5-way binding post and one SpeakonTM per channel
Indicators : Power(Blue), Protection(Red), Clip/Limiter(Red), Signal(Green), Mode Selector(Yellow)
Filters : 30Hz HPF, 50Hz HP
Protection : Turn-on delay, thermal, DC fault, PC limiter, RF, Clip-limiter, short circuit, open circuit
Cooling : Continuously variable speed fan, front to rear air flow
Power Source : 100-120VAC or 220-240VAC; 50/60Hz
(supplied AC mains transformer depends on country requirements)
Power Consumption (1/8 power, RL=4 Ω) :
120VAC : 7A
230VAC : 3.5A
Weight : 14.4kg/31.7b
Dimensions (WxHxD) : 482x88x369mm/19x3.5x14.5in
More
Less
Reviews
0 reviews
Write a review
Description
Controls :
Front : Power on/off switch, attenuator, LED indicators
Rear : Mode seletor switch (Stereo/Bridged Mono/Parallel HPF 50Hz/30Hz/off switch, limiter on/off switch)
Connectors :
Input : Combination jack and XLR jack (link)
Output : One 5-way binding post and one SpeakonTM per channel
Indicators : Power(Blue), Protection(Red), Clip/Limiter(Red), Signal(Green), Mode Selector(Yellow)
Filters : 30Hz HPF, 50Hz HP
Protection : Turn-on delay, thermal, DC fault, PC limiter, RF, Clip-limiter, short circuit, open circuit
Cooling : Continuously variable speed fan, front to rear air flow
Power Source : 100-120VAC or 220-240VAC; 50/60Hz
(supplied AC mains transformer depends on country requirements)
Power Consumption (1/8 power, RL=4 Ω) :
120VAC : 7A
230VAC : 3.5A
Weight : 14.4kg/31.7b
Dimensions (WxHxD) : 482x88x369mm/19x3.5x14.5in
Front : Power on/off switch, attenuator, LED indicators
Rear : Mode seletor switch (Stereo/Bridged Mono/Parallel HPF 50Hz/30Hz/off switch, limiter on/off switch)
Connectors :
Input : Combination jack and XLR jack (link)
Output : One 5-way binding post and one SpeakonTM per channel
Indicators : Power(Blue), Protection(Red), Clip/Limiter(Red), Signal(Green), Mode Selector(Yellow)
Filters : 30Hz HPF, 50Hz HP
Protection : Turn-on delay, thermal, DC fault, PC limiter, RF, Clip-limiter, short circuit, open circuit
Cooling : Continuously variable speed fan, front to rear air flow
Power Source : 100-120VAC or 220-240VAC; 50/60Hz
(supplied AC mains transformer depends on country requirements)
Power Consumption (1/8 power, RL=4 Ω) :
120VAC : 7A
230VAC : 3.5A
Weight : 14.4kg/31.7b
Dimensions (WxHxD) : 482x88x369mm/19x3.5x14.5in
Attributes
Attributes
| AC Line Voltage and Frequency Configurations Available | AC 100V/120V 50/60Hz, 230V/ 240V 50/60Hz |
| Amplifier Type | Power Amplifier |
| Catalog | Professional |
| Category | AMPLIFIERS |
| Channels | 2 |
| Crosstalk (below rated power) 20Hz to 1kHz > (db) | 85 |
| Depth (cm) | 36.9 |
| Frequency Response (at 1W, 4/8Ω) (dB) ± | 0/1dB 20Hz~20kHz ; -3dB : 5Hz~70kHz |
| Height (cm) | 8.8 |
| Input Inpendance | 20kΩ |
| Input Sensitivity | 2.7dBu |
| Load Impedance | Ohm |
| Manufacturer | INTER-M |
| Measurement Unit | PIECE |
| Order Quantity | 1 |
| Power Output | 450 |
| Power Output W/4Ω | 450 |
| Power Output W/8Ω | 280 |
| Power Output W/Brigde Mode/8Ω | 1400 |
| Rack Installation Possible | Yes |
| Signal to Noise Ratio (dB) | 100 |
| Total Harmonic Distortion (THD) (full rated power, 20Hz to 20kHz | 0.03% |
| Use | POWER AMPLIFIERS |
| Voltage Gain (dB) | 32 |
| Warranty Months | 12 |
| Weight (Kg) | 14.4 |
| Width (cm) | 48.2 |
