LEA AMPLIFIER 4CH 4X120Wrms

Product Code:CONNECT 124

Available

The CONNECTSERIES 124 is a 4-channel amplifier with 120 watts per channel in a ½ rack space form factor. As part of the Network CONNECTSERIES, the world’s first Internet of Things- (IoT) enabled professional-grade amplifiers, it is perfectly suited for small to medium-scale installations.
- The 124 features direct HiZ (70V or 100V) or LoZ selectable by channel.
- With three ways to connect, you can engage the built-in Wi-Fi access point, connect to the venue’s Wi-Fi, or use the FAST Ethernet to connect to any local area network via Cat5 or Cat6 cable.

Less

Call us

Reviews

0 reviews

Write a review

Description

Attributes

AC Line Voltage and Frequency Configurations Available	100VAC - 240VAC +/- 15% 50Hz or 60Hz
Amplifier Type	Power Amplifier
Catalog	Professional
Category	AMPLIFIERS
Channels	4
Crosstalk (below rated power) 20Hz to 1kHz > (db)	70dB (20Hz to 20kHz)
Depth (cm)	30
Frequency Response (at 1W, 4/8Ω) (dB) ±	20Hz - 20kHz
Height (cm)	4.3
Input Sensitivity	Balanced Inputs with user selectable 26 dB and 34 dB input sensitivity
Load Impedance	Ohm
Manufacturer	LEA
Measurement Unit	PIECE
Order Quantity	1
Power Output	120
Power Output W/100V	120
Power Output W/4Ω	120
Power Output W/8Ω	120
Rack Installation Possible	Yes
Signal to Noise Ratio (dB)	102
Total Harmonic Distortion (THD) (full rated power, 20Hz to 20kHz	0,1
Use	POWER AMPLIFIERS 100V
Warranty Months	36
Weight (Kg)	4.1
Width (cm)	21.8
