ALBALA DISTRIBUTOR AND EQUALIZER STAND-ALONE 1IN TO 8OUT

The AVD0001C01 is a wide bandwidth analog video distributor for standard definition (525 and 625 lines) and high definition (720p, 1080i and 1080p) signals. It is comprised of one section that can distribute a loop-through input signal to eigth outputs.
The AVD0001C01 includes a DC-coupled amplifier-distributor between the input and the outputs, a DC restorer with two operating mode (fast and slow) and an equalizer capable of compensating up to 300 meters of Belden 1694A controlled by two potentiometers on the side of the unit. The AVD0001C01 also allows the input to be terminated by 75 ohms when a loop-through connection is not required.
The AVD0001C01 includes an ON LED on the front panel to indicate when electrical power is connected, an LED to indicate the presence and format of the video signal being distributed and three switches to configure the DC restorer and the input termination.
