TOA AMPLIFIER 4x60W/100V INPUT MONO WITH VP-200VX MOD
Product Code:VP-2064
Available
The VP-2064 Power Amplifier features a 60 W-by-4 channels configuration, and uses the VP-200VX Power Amplifier Module per channel.
Spec Power Source 28 V DC
Current Consumption (EN60065) 4.8 A in total
Rated Output Power 60 W x 4
Output Voltage/Impedance 100 V/167 ohms, 70 V/83 ohms, 50 V/41 ohms
(selectable by the internal wiring change)
Number of Channels 4
Input Specified by input module VP-200VX
Number of Module Slots 4, usable module: VP-200VX
Output Power amplifier output (speaker line):
M3.5 screw terminal, distance between barriers: 8.8 mm
Frequency Response 40 - 16,000 Hz, +/-3 dB (at 1/3 rated output)
Distortion Under 1% (at rated output, 1 kHz)
S/N Ratio Over 80 dB
Dimensions 482 (W) x 88.4 (H) x 340.5 (D) mm
Spec Power Source 28 V DC
Current Consumption (EN60065) 4.8 A in total
Rated Output Power 60 W x 4
Output Voltage/Impedance 100 V/167 ohms, 70 V/83 ohms, 50 V/41 ohms
(selectable by the internal wiring change)
Number of Channels 4
Input Specified by input module VP-200VX
Number of Module Slots 4, usable module: VP-200VX
Output Power amplifier output (speaker line):
M3.5 screw terminal, distance between barriers: 8.8 mm
Frequency Response 40 - 16,000 Hz, +/-3 dB (at 1/3 rated output)
Distortion Under 1% (at rated output, 1 kHz)
S/N Ratio Over 80 dB
Dimensions 482 (W) x 88.4 (H) x 340.5 (D) mm
More
Less
Web Price
588.40€
Retail Price
839.50€
Reviews
0 reviews
Write a review
Description
The VP-2064 Power Amplifier features a 60 W-by-4 channels configuration, and uses the VP-200VX Power Amplifier Module per channel.
Spec Power Source 28 V DC
Current Consumption (EN60065) 4.8 A in total
Rated Output Power 60 W x 4
Output Voltage/Impedance 100 V/167 ohms, 70 V/83 ohms, 50 V/41 ohms
(selectable by the internal wiring change)
Number of Channels 4
Input Specified by input module VP-200VX
Number of Module Slots 4, usable module: VP-200VX
Output Power amplifier output (speaker line):
M3.5 screw terminal, distance between barriers: 8.8 mm
Frequency Response 40 - 16,000 Hz, +/-3 dB (at 1/3 rated output)
Distortion Under 1% (at rated output, 1 kHz)
S/N Ratio Over 80 dB
Dimensions 482 (W) x 88.4 (H) x 340.5 (D) mm
Spec Power Source 28 V DC
Current Consumption (EN60065) 4.8 A in total
Rated Output Power 60 W x 4
Output Voltage/Impedance 100 V/167 ohms, 70 V/83 ohms, 50 V/41 ohms
(selectable by the internal wiring change)
Number of Channels 4
Input Specified by input module VP-200VX
Number of Module Slots 4, usable module: VP-200VX
Output Power amplifier output (speaker line):
M3.5 screw terminal, distance between barriers: 8.8 mm
Frequency Response 40 - 16,000 Hz, +/-3 dB (at 1/3 rated output)
Distortion Under 1% (at rated output, 1 kHz)
S/N Ratio Over 80 dB
Dimensions 482 (W) x 88.4 (H) x 340.5 (D) mm
Attributes
Attributes
| AC Line Voltage and Frequency Configurations Available | 28V DC |
| Amplifier Type | Power Amplifier |
| Catalog | Professional |
| Category | AMPLIFIERS |
| Channels | 4 |
| Depth (cm) | 34.05 |
| Frequency Response (at 1W, 4/8Ω) (dB) ± | 40-16000 |
| Height (cm) | 8.84 |
| Load Impedance | 100V/70V |
| Manufacturer | TOA |
| Measurement Unit | PIECE |
| Order Quantity | 1 |
| Power Output | 240 |
| Power Output W/100V | 60 |
| Rack Installation Possible | Yes |
| Signal to Noise Ratio (dB) | >80 |
| Total Harmonic Distortion (THD) (full rated power, 20Hz to 20kHz | <1% |
| Use | POWER AMPLIFIERS 100V |
| Warranty Months | 12 |
| Weight (Kg) | 11.2 |
| Width (cm) | 48.2 |
